Onboard Interfaces and Devices

10.1

UART/RS-232 Debug Port

The conga-QMX6 is equipped with a six-pin RS232 connector onboard the conga-QMX6. This RS-232 debug port is connected to the NXP
i.MX6 UART1 and UART2 pins via the MAXIM-3232 transceiver. The transceiver is guaranteed to run at data rates of 250kbps in normal
operating mode, while maintaining RS-232 output levels.
Refer to section 5.2 for more information about the UART interface.
Table 30 UART Signal Descriptions
Pin # Signal (Molex Connector) D-SUB 1 (Console)
1 DCE1_TXT
2 NC
3 GND
4 DCE2_TXT
5 DCE2_RX
6 DCE1_RX
Note
The RS232 adapter cable (PN: 48000023) for the onboard UART interface is included in the congatec Qseven Evaluation kit. You can also
order this cable separately from congatec AG. For more information, contact your congatec sales representative.
Copyright © 2013 congatec AG
D-SUB 2
NC Pin 2
NC NC
Pin 5 Pin 5
Pin 2 NC
Pin 3 NC
NC Pin 3
Description
i.MX6 UART 5 Serial Data Transmitter
Not Connected
Ground
UART 2 Serial Data Transmitter
UART 2 Serial Data Receiver
i.MX6 UART 5 Serial Data Receiver
QMX6m12
Color
Red
-
White
Black
Orange
Purple
58/63
®
