Android Buttons

Table 33 Android Button Signal Descriptions
Onboard the conga-QMX6 is an eight pin connector for implementing android buttons. The signals are directly connected to the NXP
processor.
Signal Pin #
PWRBTN# 1
KEY_VOL_UP 2
HOME 3
SEARCH 4
BACK 5
MENU 6
KEY_VOL_DN 7
GND 8
10.6

DDR3 Memory

The conga-QMX6 offers a 2GB DDR3 SDRAM memory onboard. The memory modules are connected directly to the DDR ports of the NXP
i.MX6 processor.
10.7

eMMC

The conga-QMX6 offers a 4G eMMC module onboard. The onboard eMMC is a nand flash device and it is routed directly to the SDIO port 3 of
the NXP ® i.MX6 processor. Eight lanes are used for data. Changes to the onboard eMMC may occur during the lifespan of the module in order
to keep up with the rapidly changing eMMC technology. The performance of the newer eMMC may vary depending on the eMMC technology.
Note
For adequate operation of the eMMC, ensure that at least 15 % of the eMMC storage is reserved for vendor-specific functions.
10.8

Micro SD

The conga-QMX6 offers an onboard micro SD connector (backside of the module). It is connected to the SDIO port 2 of the NXP
processor. Four lanes are used for data.
