conga-QMX6 USB Routing Diagram
USB Device
USB 0 (Host only)
SMSC
USB 2 (Host only)
USB Host1
USB
HUB
USB 3 (Host only)
USB 4 (Host only)
Freescale® i.MX6
ARM Cortex A9
Processor
USB 1 (Host/Client)
USB OTG
Copyright © 2013 congatec AG
QMX6m12
40/63
