Pin Signal
77 USB_P7+ / USB_SSTX0+
79 USB_6_7_OC#
81 USB_P5- / USB_SSTX1-
83 USB_P5+ / USB_SSTX1+
85 USB_2_3_OC#
87 USB_P3-
89 USB_P3+
91 USB_VBUS
93 USB_P1-
95 USB_P1+
97 GND
99 eDP0_TX0+ / LVDS_A0+
101 eDP0_TX0- / LVDS_A0-
103 eDP0_TX1+ / LVDS_A1+
105 eDP0_TX1- / LVDS_A1-
107 eDP0_TX2+ / LVDS_A2+
109 eDP0_TX2- / LVDS_A2-
111 LVDS_PPEN
113 eDP0_TX3+ / LVDS_A3+
115 eDP0_TX3- / LVDS_A3-
117 GND
119 eDP0_AUX+ / LVDS_A_CLK+
121 eDP0_AUX- / LVDS_A_CLK-
123 LVDS_BLT_CTRL /GP_PWM_OUT0
125 GP2_I2C_DAT / LVDS_DID_DAT
127 GP2_I2C_CLK / LVDS_DID_CLK
129 CAN0_TX
131 DP_LANE3+ / TMDS_CLK+
133 DP_LANE3- / TMDS_CLK-
135 GND
137 DP_LANE1+ / TMDS_LANE1+
139 DP_LANE1- / TMDS_LANE1-
141 GND
143 DP_LANE2+ / TMDS_LANE0+
145 DP_LANE2- / TMDS_LANE0-
147 GND
149 DP_LANE0+ / TMDS_LANE2+
151 DP_LANE0- / TMDS_LANE2-
153 DP_HDMI_HPD#
155 PCIE_CLK_REF+
Copyright © 2013 congatec AG
Pin Signal
78 USB_P6+ / USB_SSRX0+
80 USB_4_5_OC#
82 USB_P4- / USB_SSRX1-
84 USB_P4+ / USB_SSRX1+
86 USB_0_1_OC#
88 USB_P2-
90 USB_P2+
92 USB_ID
94 USB_P0-
96 USB_P0+
98 GND
100 eDP1_TX0+ / LVDS_B0+
102 eDP1_TX0- / LVDS_B0-
104 eDP1_TX1+ / LVDS_B1+
106 eDP1_TX1- / LVDS_B1-
108 eDP1_TX2+ / LVDS_B2+
110 eDP1_TX2- / LVDS_B2-
112 LVDS_BLEN
114 eDP1_TX3+ / LVDS_B3+
116 eDP1_TX3- / LVDS_B3-
118 GND
120 eDP1_AUX+ / LVDS_B_CLK+
122 eDP1_AUX- / LVDS_B_CLK-
124 GP_1-Wire_Bus
126 eDP0_HPD# / LVDS_BLC_DAT
128 eDP1_HPD# / LVDS_BLC_CLK
130 CAN0_RX
132 RSVD (Differential Pair)
134 RSVD (Differential Pair)
136 GND
138 DP_AUX+
140 DP_AUX-
142 GND
144 RSVD (Differential Pair)
146 RSVD (Differential Pair)
148 GND
150 HDMI_CTRL_DAT
152 HDMI_CTRL_CLK
154 RSVD
156 PCIE_WAKE#
