25 GND
26 CAM1_CSI_CLK+ CSI2 Camera 1 Differential Clock+ (Strobe)
27 CAM1_CSI_CLK- CSI2 Camera 1 Differential Clock- (Strobe)
28 GND
29 CAM1_CSI_D0+ CSI2 Camera 1 Data Lane 0+
30 CAM1_CSI_D0- CSI2 Camera 1 Data Lane 0-
31 CAM1_RST# Camera 1 Reset (low active)
32 CAM1_CSI_D1+ CSI2 Camera 1 Data Lane 1+
33 CAM1_CSI_D1- CSI2 Camera 1 Data Lane 1-
34 GND
35 CAM0_GPIO GPIO for Camera 0
36 CAM1_GPIO GPIO for Camera 1
Note
conga-QMX6 Revision B.x:
For the camera interface on conga-QMX6 revision B.x to function correctly:
5. Use the latest kernel on the congatec git server. If you use older kernels (3.0.35_1.1.0 and 3.0.35_4.1.0), then you require a patch (available
on the git server) to provide the correct supply voltage for the camera module. You do not need this patch if the camera is connected on
the conga-MCB mini carrier board.
6. If you intend to connect camera module ACA1 to the camera interface, then make sure you use hardware revision X.1 of camera module
ACA1 to provide 2.5V compliant signals.
7. Set the voltage level of the camera interface to 2.5V. You can achieve this voltage level in QMX6 bootloader version 2013.04 (cgt_imx_
v2013.04_3.10.17_1.0.0) by setting the environment variable "lv_mipi" to the value "2V5".
For more information about the camera interface and the related requirements/modifications to the hardware, contact your dedicated
congatec support representative.
conga-QMX6 Revision C.x:
The conga-QMX6 revision C.x provides 3.3V to the camera interface as defined by the SGET Camera Feature Specification. Because of this
voltage level, the ACA1 hardware revision X.x is not compatible with the camera interface of conga-QMX6 revision C.x. Therefore, use only
hardware revision A.x of the camera module ACA1 (See the caution note below).
Copyright © 2013 congatec AG
P
D-PHY I Not Connected
D-PHY I Not Connected
P
D-PHY I Not Connected
D-PHY I Not Connected
CMOS 1.8V O
D-PHY I Not Connected
D-PHY I Not Connected
P
CMOS 1.8V I/O
CMOS 1.8V I/O Also for alternative camera functions like flashlight
(not specified in SGET spec.)
