LVDS_A_CLK+
119
LVDS primary channel differential pair clock lines.
LVDS_A_CLK-
121
eDP0_AUX+
Display Port primary auxiliary channel.
eDP0_AUX-
LVDS_B0+
100
LVDS secondary channel differential pair 0.
LVDS_B0-
102
eDP1_TX0+
Display Port secondary channel differential pair 0.
eDP1_TX0-
LVDS_B1+
104
LVDS secondary channel differential pair 1.
LVDS_B1-
106
eDP1_TX1+
Display Port secondary channel differential pair 1.
eDP1_TX1-
LVDS_B2+
108
LVDS secondary channel differential pair 2.
LVDS_B2-
110
eDP1_TX2+
Display Port secondary channel differential pair 2.
eDP1_TX2-
LVDS_B3+
114
LVDS secondary channel differential pair 3.
LVDS_B3-
116
eDP1_TX3+
Display Port secondary channel differential pair 3.
eDP1_TX3-
LVDS_B_CLK+
120
LVDS secondary channel differential pair clock lines.
LVDS_B_CLK-
122
eDP1_AUX+
Display Port secondary auxiliary channel.
eDP1_AUX-
LVDS_DID_CLK
127
Primary functionality is DisplayID DDC clock line used for LVDS flat panel detection. If
/GP2_I2C_CLK
primary functionality is not used, it can be as General Purpose I²C bus clock line.
LVDS_DID_DAT
125
Primary functionality DisplayID DDC data line used for LVDS flat panel detection. If
/GP2_I2C_DAT
primary functionality is not used it can be as General Purpose I²C bus data line.
LVDS_BLC_CLK
128
Control clock signal for external SSC clock chip. If the primary functionality is not used,
eDP1_HPD#
it can be used as an emedded DisplayPort secondary Hotplug detection.
LVDS_BLC_DAT
126
Control data signal for external SSC clock chip.
eDP0_HPD#
If the primary functionality is not used, it can be used as an embedded DisplayPort
primary Hotplug detection.
Note
The LVDS interface can be used either as a single channel or as a dual channel. It is also possible to use the LVDS interface as two independent
single LVDS channels. To do this, it is recommended to configure the LVDS display in the bootloader.
Copyright © 2013 congatec AG
O LVDS
O LVDS
O LVDS
O LVDS
O LVDS
O LVDS
I/O 3.3V
OD
I/O 3.3V
OD
I/O 3.3V
OD
I/O 3.3V
OD
QMX6m12
PU 4k7
3.3V
PU 4k7
3.3V
PU 4k7
Not supported
3.3V
PU 4k7
Not supported
3.3V
50/63
