2.5.7 NXP i.MX6 Cortex A9 800 MHz Dual Lite 512kB L2 cache (2GB eMMC)
®
With 2GB onboard eMMC
conga-QMX6 Art. No. 016111
Memory Size
Operating System
Power State
Power consumption (measured in Ampere/Watt)
2.5.8 NXP i.MX6 Cortex A9 800 MHz Dual Core 1MB L2 cache (2GB eMMC)
®
With 2GB onboard eMMC
conga-QMX6 Art. No. 016112
Memory Size
Operating System
Power State
Power consumption (measured in Ampere/Watt)
2.5.9 NXP i.MX6 Cortex A9 800 MHz Quad Core 1MB L2 cache (2GB eMMC)
®
With 2GB onboard eMMC
conga-QMX6 Art. No. 016113
Memory Size
Operating System
Power State
Power consumption (measured in Ampere/Watt)
Note
All recorded power consumption values are approximate and only valid for the controlled environment described earlier. 100% workload
refers to the CPU workload and not the maximum workload of the complete module. Power consumption results will vary depending on the
workload of other components such as graphics engine, memory, etc.
Copyright © 2013 congatec AG
NXP ® i.MX6 Cortex A9 800 MHz 512kB L2 cache (40nm)
Layout Rev. QMX6LB1 /Bootloader Rev. QMX6Rx07
1GB onboard
Ubuntu
Desktop Idle 100% workload
TBD A/ W TBD A/ W
NXP ® i.MX6 Cortex A9 800 MHz 1MB L2 cache (40nm)
Layout Rev. QMX6LB1 /Bootloader Rev. QMX6Rx07
1GB onboard
Ubuntu
Desktop Idle 100% workload
0.30 A/ 1.5W 0.42 A/ 2.1 W
NXP ® i.MX6 Cortex A9 800 MHz 1MB L2 cache (40nm)
Layout Rev. QMX6LB1 /Bootloader Rev. QMX6Rx07
1GB onboard
Ubuntu
Desktop Idle 100% workload
0.30 A/ 1.5 W 0.54 A/ 2.7 W
QMX6m12
Max. Power Consumption
TBD A/ W
Max. Power Consumption
0.60 A/ 3.0 W
Max. Power Consumption
0.72 A/ 3.6 W
