Installation and Operating Instructions
CONTROLLING
IMAGE DISPLAY

Screen Format

Controlling Image Display

Image display is located in the central area of the screen, where the
unit displays images. The image area is affected by the following:
• Screen Format
• Image Area Popup Menu
• Image Area Zoom
• Full-Screen Operation
• Camera Sequencing
• Live Monitor (Optional)
• Unit Schedule
You can select from the following four screen formats:

1x1

Click this button to select the single window (1x1) format. The
camera assigned to this format will display. In this format, only one
camera can be displayed at a time.
You can also click any camera button to display a camera in this
format.

2x2

Click this button to select the four-window (2x2) format. The
cameras assigned to this format will display. In this format, up to
four cameras can be displayed together.

3x3

Click this button to select the nine-window (3x3) format. The
cameras assigned to this format will display. In this format, up to
nine cameras can be displayed together.

4x4

Click this button to select the 16-window (4x4) format. The cameras
assigned to this format will display. In this format, up to 16 cameras
can be displayed together.
See Chapter 3 —System Setup
page 82 for more information.
NOTE: You must close all open screens (except playback) before
changing the screen format.
on page 97
on page 98
on page 100
on page 100
on page 101
on page 102
on page 102
on page 14 and
97
Display Setup on
