Table 8. Manual Mux Settings for All ADCs (SETADC_sw_man_en = 1)
ADC0_sw[3:0] ADC0 Connected to
0000 No connection
0001 AIN2
0010 No connection
0011 No connection
0100 AIN4
0101 AIN6
0110 No connection
0111 No connection
1000 No connection
1001 AIN1
1010 No connection
1011 No connection
1100 AIN3
1101 AIN5
1110 No connection
1111 No connection
CONNECTING
ANALOG SIGNALS
TO ADV7181B
SET INSEL[3:0] TO
CONFIGURE ADV7181B TO
DECODE VIDEO FORMAT:
CVBS: 0000
YC: 0110
YPrPb: 1001
CONFIGURE ADC INPUTS USING
MUXING CONTROL BITS
(ADC_sw_man_en, ADC0_sw,
ADC1_sw, ADC2_sw)
Figure 6. Input Muxing Overview
ADC1_sw[3:0] ADC1 Connected to
0000 No connection
0001 No connection
0010 No connection
0011 No connection
0100 AIN4
0101 AIN6
0110 No connection
0111 No connection
1000 No connection
1001 No connection
1010 No connection
1011 No connection
1100 AIN3
1101 AIN5
1110 No connection
1111 No connection
INSEL[3:0] Input Selection, Address 0x00[3:0]
The INSEL bits allow the user to select the input format. It
configures the standard definition processor core to process
CVBS (Comp), S-Video (Y/C), or Component (YPrPb) format.
Table 9. Standard Definition Processor Format Selection,
INSEL[3:0]
INSEL[3:0]
0000
0110
1001
Rev. B | Page 14 of 100
ADC2_sw[3:0] ADC2 Connected to:
0000 No connection
0001 No connection
0010 No connection
0011 No connection
0100 No connection
0101 AIN6
0110 No connection
0111 No connection
1000 No connection
1001 No connection
1010 No connection
1011 No connection
1100 No connection
1101 AIN5
1110 No connection
1111 No connection
Video Format
Composite
Y/C
YPrPb
