This appliance must only be used as described
in this handbook. The manufacturer shall
not be liable for any damage caused due to
improper, incorrect and unreasonable use.
This appliance is not suitable for use by chil-
dren or persons with reduced physical, sen-
sory or mental capabilities, or by persons with
a lack of experience or knowledge, unless
supervised or given instructions.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
The machine shall be installed only in rooms,
in which the use and the maintenance are
restricted to skilled staff.
The appliance shall not be install where water
jets can be used.
The maximum and minimum storage temper-
atures must fall within a range of [-5, +50]°C.
The operating temperature must be within the
range of [+5, +35]°C
At the end of installation, the device is
switched on and taken to rated operating
conditions, leaving it in a state in which it is
"ready for operation".
The coffee machine must not be left switched
on without supervision, that is to say without
the presence of an operator.
The Simonelli Group is not responsible for
any damage caused by malfunction of the
machine, in case this machine is left on with-
out the presence of the operator.
After reaching the "ready for operation" con-
dition, the following dispensing operations
are carried out:
100% of the coffee circuit through the
coffee dispenser (for more than one dis-
penser, this is divided equally);
100% of the hot water circuit through
the water dispenser (for more than one
dispenser, this is divided equally);
opening of each steam outlet for 1 minute.
At the end of installation, it is good practice to
draw up a report of the operations.
The use of any electrical device must comply
with fundamental regulations. In particular:
do not touch the appliance when hands
or feet are wet;
do not use the appliance when barefoot;
Edition 01 of 08/2017
SERVICE MANUAL
Fig. 5
do not use the appliance when barefoot;
do not pull the supply cord out of the
socket to disconnect it from the mains;
do not leave the appliance exposed to
atmospheric agents (rain, sun, etc..);
do not let the appliance be used by
children, unauthorised staff or staff who
have not read and fully understood the
contents of this handbook.
During installation, the mains power system
needs to be equipped with a disconnector
switch to cut off each phase.
Before carrying out any maintenance opera-
tion, the authorised service engineer will
switch off the machine and open the discon-
nector.
Fig. 6
For all cleaning operations comply exclusively
with the instructions given in this booklet.
WARNING
RISK OF SHORT CIRCUITS
OK
