13.2

POST CODES

BIOS POST CODES
Checkpoint Function Name
FOh Reset Vector
80h UserPrelnit
00h PreSiolnit
01h Clocklnit
02h GxmReglnit
03h UnReal
04h gxmMemReg1nit
05h gxmTest
06h MemSetup
memTest-
PinCheck
07h memSetUpStack
08h memTest
09h shadowRom
Intermediate Function Description
Codes
FOh XpressROM code execution start
--- User added code to be run first
60h First SIO access, Core SIO initialize, LPT can be
mapped to 1/0 80h for
embedded devices to provide POST code output.
--- Chipset level clock initialize
--- 1/0 based Geode initialize
--- Create a 32-bit real mode descriptor
--- Memory mapped 1/0 based Geode initialize
--- Geode CPU tests
20h Test entry
28h- 2Fh Test stepping ID (2Fh = Test Failed)
2Ah Test feature
2Eh Test passed exit
--- Auto size memory controller DIMM I and DIMMO
70h Set the clock drive strength and shift value, mask the
clocks
72h Set the data, address, and control drive, clear refer-
ence timer and VGA
wrap
73h Set the register to indicate no DIMMs installed
74h Default CAS latency to 3
75h or 7Fh Memory sizing (7Fh = No memory located)
76h Do refresh
7E MemSetup exit
--- See if MTEST pins to be enabled
--- Setup a stack
90h or 9Fh Create stack (9Fh = Stack creation failure)
9Eh Stack setup exit
--- Test memory address lines
BOh Test memory
BEh Memory test exit
BFh Memory test failed (i.e., BOh)
--- Copy ROM from FOOO:0000 to RAM at FOOO:0000
