J17 10/100 BASE-T interface connector
J17 Pin * Signal
Pin 1 = TX-
Pin 2 = TX+
Pin 3 = RX-
Pin 4 = RX+
Pin 5 = Activity LED
Pin 6 = BAT input 3.0-3.6V
Pin 7 = GND
Pin 8 = VCC 3.3V
Pin 9 = Speed LED
Pin 10 = Link LED
At the J17 must be connecte the LAN-Interfaceboard including the LAN-Transformator and the Lithium RTC-
Battery for backup.
J16 Sound/Audio Port
Pin Signal
1 Input_CD_L
3 Input_CD_R
5 GND
7 Input_Line_L
9 Input_Line_R
11 Input_MIC 1
13 Input_MIC 2
15 Output_Left
17 Output Right
19 Output_S_Left
21 Output_S_Right
23 Output_Center
25 Output_Subwoofer
27 SPDIF Digital Output
29 Jack Sense 1 Input
J8 LPC-Port
Only for factory and POD-Diagnostic use.
Pin Signal
1 VCC 3.3V
3 LFrame#
5 PCI_RST#
7 FWH_TBL#
9 VCC 5V
11 LPC_Clock
13 Ground
J4 JTAG-Port
Pin Signal
1 TCK
3 TDI
Signal
Pin Signal
2 GND
4 Input_AUX_L
6 Input_AUX_R
8 GND
10 GND
12 GND
14 Input Mono
16 GND
18 GND
20 GND
22 GND
24 GND
26 GND
28 Jack Sense 0 Input
30 Jack Sense 2 Input
Pin Signal
2 LAD0
4 LAD1
6 LAD2
8 LAD3
10 PCI_RST#
12 nc
14 FWH_Control
Pin Signal
2 TMS
4 TDO
