4 D
ETAILED
This system has a system configuration based on the ISA architecture. Check the I/O and the Memory map
in this chapter.
4.1

Power Requirements

The power is connected through the PC/104 power connector; or the separate power connector on the
board. The supply uses only the +5 Volts and ground connection.
Warning:
Tolerance of 5V supply:
Testenvironment for powerconsumption measurement:
Peripheries:
Harddisk Hitachi Mod-HTS424020M9AT00 20Gb
Monitor Eizo Flexscan F340i.W
PS/2-KB Logitech Mod-iTouch Keyboard
PS/2-MS Logitech Mod-M-CAA43
Floppy TEAC Mod-FD-05HF
Software:
MS-DOS V6.22
WinXP
Current consumption @ 5Volt supply at –40° C/+25° C/+85° C
Mode
MSM800SEV-500MHz
DOS: C:\
Win2000: Desktop
4.2

Boot time

System Boot-Times
Definitionen/Boot-Medium
MSM800SEV-500MHz
From Harddisk-Hitachi Mod-DK233AA-60:
Boot from Harddisk to „Starting MS-DOS".-Prompt.
Boot from Hardisk to XP desktop
Booting without a storage device (only bios)
S D
YSTEM ESCRIPTION
Make sure that the power plug is wired correctly before supplying power to the
board ! A built-in diode protects the board against reverse polarity.
5 volts ± 5%; Power-fail signal starts at ± 10 % of 5 volt norm and generates a
reset status for the MICROSPACE PC.
Memory DLAG-Nr.
1GB
1GB
-30 ° C
[mA]
22
MSM800 SEV Manual V1.0A
+25° C +85 ° C
[mA] [mA]
1600
1600
Quick Normal
Boot Boot
time [s] time [s]
- 17
- 45
10
