ESCRIPTION OF THE CONNECTORS
Flat cable
•
44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable
•
All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable
Connector
J1
PC104+
J10
COM2
J11
Keyboard, mouse, utility
J12
IrDA
J13
LPT1
J14
Floppy
J15
PC104
J16
Sound Audio I/O
J17
LAN / Battery
J19
Power, PM,
J2
VGA
J3
IDE
J4
JTAG-Port
J5
USB 1
J7
USB 2
J9
COM1
U1
SODIMM
X1
LCD
X2
Compact Flash Holder
Texture
41
MSM800 SEV Manual V1.0A
Pin
Remarks
120
2mm
2x5
2.54mm
2x5
2.54mm
4
2.54mm
2x13
2.54mm
26
FCC micro
104
2.54mm
2x15
2.00mm
2x5
2.00mm
2x4
2.54mm
2x5
2.54mm
2x22
2mm
4
2.54mm
4
2.54mm
4
2.54mm
2x5
2.54mm
144
0.8mm
2x22
2mm
