Physical Characteristics:
Dimensions:
Weight:
PCB Thickness:
PCB Layer:
Operating Environment:
Relative humidity:
Vibration:
Shock:
Temperature:
EMI / EMC (IEC1131-2 refer MIL 461/462):
ESD Electro Static Discharge:
REF Radiated Electromagnetic Field:
EFT Electric Fast Transient (Burst):
SIR Surge Immunity Requirements:
High-frequency Radiation:
Compatibility:
MSM800SEV:
Any information is subject to change without notice.
2.5

Ordering codes examples

Will follow in a later version of this manual
Length: 91 mm
Depth: 96 mm
Height: 25 mm
170 gr
1.6 mm / 0.0625 inches nominal
Multilayer
5 - 90% non condensing
5 to 2000 Hz, 0.1G
1 G
Operating*: Standard version: - 0° C to +70° C
Extended version: -40° C to +85° C
Storage: -55° C to +85 ° C
* = with passive cooler
IEC 801-2, EN55101-2, VDE 0843/0847 Part 2
Metallic protection needed
separate Ground Layer included
15 kV single peak
IEC 801-3, VDE 0843 Part 3, IEC770 6.2.9.
not tested
IEC 801-4, EN50082-1, VDE 0843 Part 4
250V - 4kV, 50 ohms, Ts=5ns
Grade 2: 1KV Supply, 500 I/O, 5Khz
IEC 801-5, IEEE587, VDE 0843 Part 5
Supply:
I/O:
FD, CRT:
EN55022
Mechanically compatible to our MSMx86 Boards and to all other
PC/104 boards
11
MSM800 SEV Manual V1.0A
2 kV, 6 pulse/minute
500 V, 2 pulse/minute
none
