DIGITAL-LOGIC AG
7 J
UMPER LOCATIONS ON THE BOARD
Jumper locations on the board
The figure shows the location of all jumper blocks on the MSM800SEV board. The numbers shown in this
figure are silk screened on the board so that the pins can easily be located. This chapter refers to the indi-
vidual pin for these jumpers. The default jumper settings are indicated with asterisks. Be careful when you
change some jumpers.
Some jumpers are soldering bridges, you need a miniature soldering station with vacuum pump.
7.1
The jumpers on MSM800SEV V1.1
Jumper
J6
Compact Flash select
J20
Powerswitch
Settings written in bold are defaults!
Texture
53
MSM800 SEV Manual V1.0A
1-2 = open
Slave
Push button
2-3 = closed
Rem
Master
always on
Top
