4.9

BIOS

4.9.1

Core bios download

Before downloading a BIOS, please check as follows:
Make a bootable diskette including the following files:
-
Flashrom.com
-
core BIOS xxxxxxxx.yyy
-
IMPORTANT:
Do not use boot disks created in a Windows operating system. If you do not have a MSDOS 6.22 disk avail-
able, you can download a boot disk from
NOTE:
Select the SHADOW option in the BIOS, for a BIOS and VGA (if this option is available).
-
Disable the EMM386 or other memory managers in the CONFIG.SYS of your bootdisk.
-
Make sure, that the Flashrom.com programm and the BIOS to download are on the
-
same path and directory!
Boot the DOS without config.sys & autoexec.bat -> press "F5" while starting DOS boot.
-
Is the empty diskspace, where the Fhlashrom.com is located, larger than 64kB (for safe storage)
-
Is the floppydisk not write-protected
-
Start the DOWNLOADING process:
1. Start the system with the bootable diskette. If you do not have a bootable diskette or floppy drive
2. you may can start in DOS mode by pressing the F5 key to disable the autoexec.bat and config.sys.
3. Run Flashrom.com (In some cases you have to ty the following: "FLASHROM /D /sFFFC0000 bios-
name.xxx")
4. Power off the system
After power on the system, press "F1" to enter the setup, set the default values and "save and leave"
the setup
5. Switch off the system after the download is finished
If the download does not work:
Check, if no EMM386 is loaded.
-
Check, if no peripheral card is in the system, which occupies the same memory range. Disconnect this
-
card.
If the download is stopped or not completed, make only a warm boot and repeat the steps or download
-
another file. As the video is may shadowed, everything is visible and a cold boot would clear the screen
and nothing would be visible afterwards.
www.bootdisk.com .
