DIGITAL-LOGIC AG
8.3
The printer interface cable
IDT terminal for dual row 0.1" (2.54mm grid) and 1.27 mm flat cable
ATTENTION:
-
Maximum length of this cable is 6 meters.
-
Prevent short-circuits.
-
Never apply power to these signals, the MICROSPACE MSM800SEV will be destroyed.
Parallelport Cable LPT1
56
MSM800 SEV Manual V1.0A
1
14
2
15
24
12
25
13
