12.1.2

Int15 emulator driver for Windows

12.1.2.1 Int15 Hardware
Resources:
1. EEPROM - 2K size
000h-3FFh - reserved
400h-7FFh - free for user data
2. Temperature sensor
3. Watchdog hardware.
Access to these resources under DOS can be provided by INT 15h function, see chapter
Access under Windows 98, ME , 2000, XP can be provided over "Int15dl"-WDM driver, under Windows-NT
"Int15dl"-NT driver.
For the moment this driver support all Digital-Logic boards with PIIX4 and ICH4 chipsets (eg. MSM855,
MSEBX855, MSMP5SEV, MSMP3SEV, MSEP800...).
Please find the driver under: \products\***\TOOLS\int15dl on the product CD or in the download area of the
support center.
12.1.2.2 Int15 Windows Software
WinInt15.exe (Int15 function test tool)
-
T855.exe (Temperatur sensor (SMBUS) monitor)
-
12.1.2.3 Driver Installation W2k/XP
"Int15dl" is not plug and play driver, it must be installed manually.
1. Open "Control Panel"
2. Doubleclick on "Add/Remove Hardware"
3. To continue click "Next>" button
4. On the page "Choose a Hardware Task" check "Add/Troubleshoot a device" and click "Next>" button
5. After "New hardware detection" windows automatic procedure, choose "Add a new device" item and click
"Next>" button
6. In the "Find New Hardware" page choose "No, I want to select the hardware from a list" and click "Next>"
button
7. Choose "Other devices" in the "Hardware Type" list and click "Next>" button
8. On the page "Select a Device Driver" press "Have Disk..." button and find the driver location (Int15dl.inf -
WDM). After opening the "inf" file, installation program will show a Models list and "Digital-Logic INT15
functions emulator" string. Then press "Next>" button
9. Then press "Finish" button, it's not necessary to restart a computer after installation
10. After installation, please, be sure, that "Digital-Logic INT15 functions emulator" has been installed
properly. Open "Control Panel", then doubleclick on "System" icon. Choose tabsheet "Hardware" and click on
"Device Manager" button. Then expand "System Devices" and doubleclick on "Digital-Logic INT15 functions
emulator". Be sure, that device is working properly.
