X1 LCD TFT Interface (flatpanel signals)
Pin Signal
1 FPM (out)
2 CRT-Vert.Synch
3 Enable BKL (TTL out)
4 CRT:Horiz.Synch
5 VCC 3.3V
6 Ground
7 nc
8 Shift Clock
9 Enable VDD (TTL out)
10 FP0
11 FP1
12 FP2
13 FP3
14 FP4
15 FP5
16 FP6
17 FP7
18 FP8
19 FP9
20 FP10
21 FP11
22 FP12
23 FP13
24 FP14
25 FP15
26 Ground
27 FP16
28 FP17
29 FP18
30 FP19
31 FP20
32 FP21
33 FP22
34 FP23
35 nc
36 nc
37 nc
38 nc
39 nc
40 nc
41 Ground
42 nc
43 +5Volt Output
44 +12V Output
TFT 18 Bit TFT 24 Bit
LDE LDE
VSYNC VSYNC
HSYNC HSYNC
CKL CKL
ENLVDD ENLVDD
Blue 0
Blue 1
Blue 0 Blue 2
Blue 1 Blue 3
Blue 2 Blue 4
Blue 3 Blue 5
Blue 4 Blue 6
Blue 5 Blue 7
Green 0
Green 1
Green 0 Green 2
Green 1 Green 3
Green 2 Green 4
Green 3 Green 5
Green 4 Green 6
Green 5 Green 7
Red 0
Red 1
Red 0 Red 2
Red 1 Red 3
Red 2 Red 4
Red 3 Red 5
Red 4 Red 6
Red 5 Red 7
