DIGITAL-LOGIC MICROSPACE MSM800SEV Technical User's Manual page 10

DIGITAL-LOGIC AG
Mass Storage:
FD:
HD:
Standard AT Interfaces:
Serial:
Parallel:
Keyboard:
Mouse:
Speaker:
RTC:
Backup current:
Battery:
BUS:
PC/104plus
Clock:
USB:
USB:
Transferrate:
Channels
Peripheral Extension:
ISA
PCI
Power Supply:
Working:
Power Rise Time:
Current:
Suspended
Floppy disk interface, for max. 1 floppy with 26pin connector
E-IDE interface, AT-type, for max. 2 harddisks, 44pin connector, for
1.3, 1.8 and 2.5" harddisk with 44 pins IDE
Name FIFO
COM1 yes
COM2 yes
(Baudrates: 50 - 115 KBaud programmable)
LPT1 printer interface mode: SPP(output), EPP (bidir.)
AT or PS/2 –keyboard
PS/2
0.1 W output drive
Integrated into PIIX4, RTC with CMOS-RAM 256Byte
<5 µA
3 Volt Lithium 300mAh internal or external connected, not chargeable
IEEE-996 standard bus, buffered
8 MHz defined by the GEODE
V2.0
400MBps, 12.5 MBps / 1.5MBps
2
With PC/104 BUS (ISA 16Bit DMA limitation)
With PC/104plus BUS
5 Volts ± 5%
Unspecified
2.5 Amp. Typical (MSM800SEV, HDD, FDD)
0.05A
10
MSM800 SEV Manual V1.0A
IRQs Addr.
IRQ4 3F8
IRQ3 2F8
Standard Option
RS232C
RS232C
