Game ready GRPro 2.1 CONTROL UNIT User Manual page 56

Table 4 for RF Immunity
RECOMMENDED SEPARATION DISTANCES BETWEEN PORTABLE
AND MOBILE RF COMMUNICATIONS EQUIPMENT AND THE GRPRO 2.1
The GRPro 2.1 is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer or the user of the GRPro 2.1 can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile
RF communications equipment (transmitters) and the GRPro 2.1 as recommended below,
according to the maximum output power of the communications equipment.
RATED MAXIMUM OUTPUT
POWER OF TRANSMITTER
W
0.01
0.1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended separation
distance d in meters (m) can be estimated using the equation applicable to the frequency of the
transmitter, where P is the maximum output power rating of the transmitter in watts (W) according
to the transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
WARNINGS:
Medical Electrical Equipment needs special precautions regarding EMC and needs to be
installed and put into service according to the EMC information provided in the User's
Manual.
Portable and mobile RF communications equipment can affect Medical Electrical
Equipment.
The GRPro 2.1 System has to be powered with the AC adapter FSP Group Inc. model
FSP 030-RCAM or Mega MDM-030-A120-5396 power supply in order to be compliant
with IEC/EN 60601-1-2 section 6.1 and 6.2.
The use of accessories, transducers and cables other than those specified and sold
by the manufacturer of the GRPro 2.1 System as replacement parts for internal
components may result in increased emissions or decreased immunity of the medical
electrical system.
The GRPro 2.1 System should not be used adjacent to or stacked with other equipment.
If adjacent or stacked use is necessary, the GRPro 2.1 System should be observed to
verify normal operation in the configuration in which it will be used.
EN- 22
SEPARATION DISTANCE ACCORDING TO FREQUENCY OF TRANSMITTER
150 KHZ TO 80 MHZ
d = 1.2 √P
0.12
0.38
1.2
3.8
12
80 MHZ TO 800 MHZ
d = 1.2 √P
0.12
0.38
1.2
3.8
12
800 MHZ TO 2.5 GHZ
d = 2.3 √P
0.23
0.73
2.3
7.3
23
