3.2 Configuration Jumpers

The S5U13A05B00C has five jumper blocks which configure various setting on the board.
The jumper positions for each function are shown below.
Jumper
Function
JP1
CLKI Source
JP2
CLKI2 Source
JP3
LCD Panel Voltage
JP4
PCI_IRQ Disable
JP5
GP00 Polarity on H3
= recommended settings
S5U13A05B00C Rev 1.0 Evaluation Board
Rev. 1.1
All manuals and user guides at all-guides.com
Table 3-2: Jumper Summary
Position 1-2
VCLKOUT from clock
synthesizer
MCLKOUT from clock
synthesizer
+3.3V LCDVCC
Enable USB IRQ on PCI
Normal (Active High)
Seiko Epson Corporation
Installation and Configuration
Position 2-3
External oscillator (U6)
BUSCLK from Header H5
External oscillator (U7)
+5V LCDVCC
Disable USB IRQ on PCI
Inverted (Active Low)
No Jumper
GPO0 not sent to H3
9
