Setting Measurement Parameters

To take a completely manual measurement (i.e. you set all
parameters yourself) use the Manual Setup option.
•
From the Main Menu press
select Manual Setup. This opens the Set Parameters Menu.
•
Change the parameter settings as required. Alternatively
select a pre-existing parameter set by pressing
arrow keys to highlight a parameter set then press
select it.
•
To take a measurement press
Taking Measurement in Measure Mode (page 29) for full
instructions for taking measurements. Ignore the first four
steps as these refer to using the quick setup menus to take a
measurement.
Some parameter values can be changed directly in this menu e.g.
press
the channel(s) used to take the measurements.
For other parameters, pressing a number key will open another
menu where you can change the parameters settings for that menu
item e.g. pressing
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
to change the number of spectral lines or
Fmin opens the Change Fmin Value Menu.
Section 4: Manual Setup Measurement Parameters
Measure then press
. See Walk-through:
to toggle
to
. Use the
to
63
