Resetting an incorrect RPM
If the RPM was specified incorrectly when a recording was taken this
can be corrected either in the vb instrument or in the Ascent
software.
•
With the spectrum or waveform displayed press
display the Enter Rotor Speed Menu.
•
Enter the correct RPM then press
display.

Erasing Recordings

•
From the Select Recording Menu press
highlighted item then
Transferring Recordings from the
Instrument
•
Plug your instrument into the PC using the communications
cable (RS232).
•
Turn on the instrument and click the Ascent Receive button
to transfer data from the instrument to your PC.
You do not need to make sure that you have the correct folder open;
the software stores a hidden key in the instrument for every folder
that determines where it belongs.
If you have a single folder defined in the instrument the receive
process will proceed automatically. If there are multiple folders in the
instrument you will be presented with a screen allowing you to select
which folder(s) to transfer.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
to return to the chart
+ to confirm.
Section 5: Recording Data
to
to erase the
