Setting the Number of Samples

•
From the Set Parameters Menu, when Time mode is
selected press
1024, 2048, 4096 or 8192 (16 384 for the vb3000).
The resolution of the waveform increases with the number of
samples used i.e. the more samples, the more information the
waveform contains. However, the more samples in a waveform, the
more memory is used up to store the waveform.
Tip: An easy way to select the number of samples and duration is to
let the instrument set them for you. In Frequency mode (option 1 in
the Set Parameters Menu), select the Fmax and number of lines
then switch to Time mode and the instrument will select the
corresponding values.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
to cycle the number of samples between
Section 4: Manual Setup Measurement Parameters 79
