Walk-through: Taking Measurements in
Measure Mode
Onsite analysis using Measure Mode involves watching a machine's
vibration on-screen as it occurs and analyzing the measurement on
the instrument (rather than recording the vibration then transferring it
to Ascent for later analysis using the software). This method of
measuring allows you to take a quick look at a machine's vibration
patterns without having to save the recording or create a machine
and points etc. You can still store the recording once the
measurement is complete if you choose to do so.
Warning: Take care of personal safety when taking measurements
in industrial environments. Follow all safety regulations at all times.
Read also Precautions (page 6), before attempting to take
measurements.
•
From the Main Menu press
•
Choose a quick setup option or one of the automated menus
e.g. Time Synchronous Averaging or Cross Channel Phase.
•
Press
running speed (RPM).
•
Press
•
Attach the sensor (and tachometer if you are taking rotor
speed and phase angle measurements).
•
Start the machine and allow it to operate under its normal
load and running speed.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
and use the number keys to enter the machine
to continue.
Section 3: Onsite Analysis - Measurement Menu
Measure.
29
