Spectrum Quick Setup - Commtest Instruments vb Series Instrument Reference Manual

1. Spectrum Quick Setup

•
From the Main Menu press
Measurement Menu.
•
From the Measurement Menu press
Setup.
The only parameter you need to set is the Fmax value. This can be
done in two ways:
OR
•
•
Once the Fmax is set press
menu then press
When a measurement has been taken it can be analyzed
immediately on the instrument (see Analyzing Measurements on
page 55) or stored for later analysis (see Storing Measurements on
page 54).
32 Section 3: Onsite Analysis - Measurement Menu
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Press to display the Machine Running Speed Menu
then use the number keys to enter an RPM value. The
Fmax will be set to 40 x the RPM (or rounded up to the
closest value).
to display the Set Fmax Menu and use
Press
to select a value.
Measure, to open the
to return to the quick setup
to take the measurement.
Spectrum Quick
or
