Operating Overview

The instrument can be used to perform the following tasks:
•
Taking live measurements for onsite analysis of vibration
spectra and waveforms
•
Recording of vibration data for transferral to a PC
•
Single and dual plane balancing

Onsite Analysis (Measure Mode)

Vibration spectra and waveforms are measured and analyzed onsite.
This is suitable for one-off investigations and involves these steps:
•
Measurement parameters are set on the instrument.
•
The spectrum or waveform is measured and analyzed
onsite.
•
The data is recorded to memory (optional).
•
The data is transferred to a PC for further analysis (optional).
See Onsite Analysis (page 28) for more information.
8 Section 1: Introduction
