Commtest Instruments vb Series Instrument Reference Manual page 39

•
To start the measurement press
•
Wait for the sensor and vb hardware to settle. When the
settling time has elapsed or the hardware has settled
measuring begins and the spectrum, waveform or
tachometer reading is displayed and continually updated.
(You can press
the remaining settling time but this is not recommended as
the measurement may not be accurate.)
•
To stop the measurement from updating press
resume measuring and updating the display press
again. Some basic analysis can be carried out straight away
including displaying the amplitude of a spectral peak and
identifying any harmonics (see Analyzing Measurements on
page 55).
•
To save the measurement press
menu and select option
•
Select or create a machine, point and direction to save the
recording to.
OR
•
To stop viewing the measurement and exit without saving
press
30 Section 3: Onsite Analysis - Measurement Menu
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
while the instrument is settling to cancel
twice to return to the Main Menu.
to display a pop-up
Record.
. To
