Walk-through: Taking Recordings

The following instructions assume that you have already created the
machines you intend to take recordings of.
Warning: Take care of personal safety when taking recordings in
industrial environments. Follow all safety regulations at all times.
Also read Precautions (page 6) before attempting to take recordings.
•
Check the battery capacity of the instrument and if it is less
than 30%, charge the battery pack. See Battery
Management (page 161) for more information.
•
Select the folder containing the machines you wish to
monitor. From the Main Menu press
Management. The first menu item shows the name of the
currently selected folder. If your folder is already selected
please skip the next step, otherwise press
Select Folder Menu.
•
Press
select it. This loads the folder into current memory and
returns you to the Folder Management Menu.
•
Press
•
From the Main Menu press
Machine Menu.
•
Press
recordings are to be taken then press
machine.
•
In the Select Point Menu select the point for which
recordings are to be taken then press
•
In the Select Direction Menu select the direction for which
recordings are to be taken then press
82 Section 5: Recording Data
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
or to highlight a folder then press
to return to the Main Menu.
or to highlight the machine for which
Folder
to display the
to access the Select
to select the
to
