Suggest Trial Weight Angle

This tool aids you in determining where on the rotor to place the trial
weight after an initial reading has been taken. The aim is to reduce
the initial vibration in order to maximize the accuracy of the trial
weight readings.
This function suggests a trial weight angle based on the phase of the
initial reading, the angle between the tachometer and accelerometer
sensors
and your weight reference mark on the rotor
angle is measured from the weight reference mark in the direction of
the Angle Orientation.
•
From the Balancing Menu press
•
Press
134 Section 9: Balancing Rotors
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
and the angle between the tachometer reflective tape
to take your initial reading.
. The suggested
Trial Readings.
