Waveform Quick Setup - Commtest Instruments vb Series Instrument Reference Manual

Setting your own parameters
Option
your own settings instead of the factory defaults. See Custom Setups
(page 57) for more information.

2. Waveform Quick Setup

•
From the Main Menu press
Measurement Menu.
•
From the Measurement Menu press
Setup.
The only parameter you need to set is the duration value. This can
be done in three ways:
OR
OR
•
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Custom Setup allows you to customize this menu to use
Press to display the Machine Running Speed Menu
then use the number keys to enter an RPM value. The
duration will be set to the time it takes the machine to
make 20 revolutions.
Press to display the Set Duration Menu and use
or to select a value.
Press to display the Set Fmax Menu and use
to select a value. The value you select will determine
the equivalent duration value. If the waveform is later
transferred to Ascent and displayed as a spectrum, this
Fmax value will be used on the chart.
Section 3: Onsite Analysis - Measurement Menu
Measure, to open the
Waveform Quick
or
