Creating a Direction/Axis

•
Create a point as described in the previous topic: Creating a
Point (page 111).
•
From the Select Point Menu press
•
Press
•
Press
All points share the same direction names. The first six default
direction names cannot be edited.
To create a new direction
•
Press
Direction Menu and press
Menu.
•
Enter a name for the direction by choosing characters from
the keyboard (see Entering Text and Numbers on page 16,
for details of how to do this).
•
Press
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
or to highlight a direction/axis.
to select the highlighted direction/axis.
or to highlight a question mark in the Select
to save the name.
to display the Edit Name
Section 8: Creating Machines 113
