Setting the Display Options

Display options control the way a measurement is displayed on the
instrument such as showing the frequency in Hz or CPM, or setting
the amplitude type to rms, Ø-peak or peak-peak.
•
To access the Display Options Menu, from the Main Menu
press
Note: This screen shot shows the factory default settings (the
measurement mode is set to frequency for spectra and the quantity
to velocity). Your screen may differ depending on the settings you
have chosen.
•
To change any of the display options press the
corresponding number key to cycle through the available
options. When you have finished press
previous screen.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Measure then press
Section 3: Onsite Analysis - Measurement Menu
twice.
to return to the
59
