B.2 J2 Connector
Table A-2: J2 connector
Pin Z
22 GND
21 GND
20 GND
19 GND
18 GND
17 GND
16 GND
15 GND
14 GND
13 GND
12 GND
11 GND
10 GND
9 GND
8 GND
7 GND
6 GND
5 GND
4 GND
3 GND
2 GND
1 GND
#: Low active
Note: GA[4...0] shall be used for geographic addressing on the backplane
A B
GA4 GA3
CLK6 GND
CLK5 N/C
N/C GND
N/C N/C
N/C GND
N/C N/C
N/C GND
AD[35] AD[34]
AD[38] GND
AD[42] AD[41]
AD[45] GND
AD[49] AD[48]
AD[52] GND
AD[56] AD[55]
AD[59] GND
AD[63] AD[62]
C/BE[5]# 64EN#
V(I/O) N/C
CLK4 GND
CLK2 CLK3
CLK1 GND
C D
GA2 GA1
N/C RSV
N/C GND
N/C N/C
N/C GND
PRST# REQ6#
DEG# GND
FAL# REQ5#
AD[33] GND
V(I/O) AD[37]
AD[40] GND
V(I/O) AD[44]
AD[47] GND
V(I/O) AD[51]
AD[54] GND
V(I/O) AD[58]
AD[61] GND
V(I/O) C/BE[4]#
C/BE[7]# GND
GNT3# REQ4#
SYSEN# GNT2#
REQ1# GNT1#
MIC-3366 Series User Manual -- Page 51
E F
GA0 GND
RSV GND
N/C GND
N/C GND
N/C GND
GNT6# GND
N/C GND
GNT5# GND
AD[32] GND
AD[36] GND
AD[39] GND
AD[43] GND
AD[46] GND
AD[50] GND
AD[53] GND
AD[57] GND
AD[60] GND
PAR64# GND
C/BE[6]# GND
GNT4# GND
REQ3# GND
REQ2# GND
