You can enable or disable the generation of link pulse signals for an
individual port. In an 802.3 10BASE-T compliant network, leave this
option at the default setting. If you are using non-compliant
transceivers that do not use the link pulse signal, you will need to
disable link pulse to enable the network to function correctly.
Alternatively, you can replace non-compliant transceivers with
10BASE-T compliant transceivers, such as the ISOLAN TP Transceiver
(3C16810).
Disabling generation of link pulses also disables detection of link pulses.
In this case, repeater ports will assume that there is a connection and
light the appropriate LEDs, even if there is no connection.
You cannot disable the link pulse for a port that is the main or standby
port of a resilient link pair.
Link State (Read-only) This field shows the connection state of each
port.
Table 3-5 Link States
Link State
Other
Unknown
Available
Not Available
Lost Links (Read-only) The number of times the link has been lost
since the Module was last reset.
Partition State (Read-only) This field shows whether or not the port
has autopartitioned. If it has, check the cabling at both the unit and
any devices connected to that port.

Port Resilience

Resilient Links may be set up ONLY on Hub 10 and FMS II Units.
DUA1663-0BAA03
Description
The link state of this port cannot be recognized (for Coax and
AUI ports.)
The port is initializing. Its actual state is not yet known.
The port is operating normally.
The link has been lost (for 10BASE-T and 10BASE-FL ports).
Repeater Management 3-39
