Serial Port Setup

You can access the Serial Port Setup screen by actuating the SERIAL
PORT button on the Setup screen.
Figure 3-8 Serial Port Setup Screen
If you alter the serial port parameters and select OK, you will terminate
any existing session using the serial port. Ensure that the connected
equipment's serial port parameters are set to match the new
configuration. This will allow you to continue to access the
management facility using the equipment after you change the serial
port parameters.
If you change the serial port parameters with Auto Config already set
to Enabled, or if you change Auto Config to Enabled, you will need to
perform the wake-up procedure (see
before communication is re-established.
Connection Type (Choice Field) Local / Remote
Select Remote if you want to manage the stack via a modem. DCD
Control and DSR Control will be enabled. Otherwise, leave this
parameter at the default setting.
DCD Control (Choice Field) Enabled / Disabled
Check in the manual for your modem if you are not sure of the correct
setting.
DUA1663-0BAA03
3Com SuperStack II Serial Port
Connection Type:
DCD Control:
DSR Control:
Flow Control:
AutoConfig:
Speed:
Char Size:
Parity:
Stop Bit:
OK
Local
Enabled
Disabled
XON/XOFF
Disabled
9600
8
None
1
CANCEL
"Main Banner"
Setup 3-15
on page 3-6)
