3-16 C 3: U VT100 M I
HAPTER SING THE ANAGEMENT NTERFACE
DSR Control (Choice Field) Enabled / Disabled
If DSR Control is enabled, the management port will be logged out if
DSR is deasserted. Check in the manual for your modem if you are not
sure of the correct setting.
Flow Control (Choice Field)
XON/XOFF / NONE / RTS - CTS Unidirectional / RTS - CTS Bidirectional
Select the flow control option that corresponds with your terminal or
modem.
Auto Config (Choice Field) Enabled / Disabled
The Module can automatically configure the terminal speed to work with
your VT100 terminal. Note that the setting made by automatic
configuration is not displayed on the screen. The displayed setting is that
which will be adopted when automatic configuration is next disabled. Set
this field to Enabled if you require automatic configuration.
To start automatic configuration detecting and setting the correct
speed, the wake-up procedure (typing [Return] [Return]) must be
performed.
Speed (Choice Field) 1200 / 2400 / 4800 / 9600
Select the baud rate for your terminal or modem. Check in the manual
for your terminal or modem if you are not sure of the correct setting.
Char Size (8), Parity (NONE) and Stop Bit (1) are fixed.
Attempts to set invalid serial port parameters will be rejected. All
parameters will be reset to their default values.
DUA1663-0BAA03
