2.2 Product configuration
The product configuration of this controller is as follows.
●Electric actuator
*1)
*1) *5)
● Actuator cable
【Part No】
LE-CP-#-#
*3)
Controller power supply
24 VDC
*1) These items are included when ordered using the part number for the electric actuator set.
*2) Please download the controller configuration software from the SMC website.
*3) 24 VDC power supply for controller input and 24 VDC power supply for parallel I/O signal should be
separated.
*5) PC is prepared by the user.
*6) Optional.
Refer to section "4. External Connection for wiring"P.21.
Refer to "12. Wiring of cables/Common precautions"P.62 when handling the wiring and cables.
Do not connect the teaching box, LAN equipment, or LAN cable directly to a PC.
Otherwise, the controller, PC or equipment may be damaged.
●
I/O cable
Part No: LEC-CN5-#
●
Controller
to ENC
to MOT
to PWR
●Power supply plug (accessory)
Part No:JXC-CPW
Applicable cable size
2
AWG20(0.5mm
)
to SI
●Conversion cable
Part No:P5062-5
●Teaching box
(with 3m cable)
Part No: LEC-T1-3#G#
Warning
- 7 –
Prepared by user
PLC
*1)
Parallel I/O
Signal power supply
24 VDC
DC24V
*5)
Option
●Controller
communication cable
Part No:JXC-W2A-C
*2) *4)
PC
or
●USB cable
(A-miniB type)
Part No:LEC-W2-U
https://www.smcworld.com/
No.JXC※-OMY0002
