7.2 Basic parameter

The "Basic parameter" is the data to define the operating conditions of the controller, conditions of the
electric actuator, etc.
Writing of the parameter should be performed while the electric actuator is stopped.
Details of basic parameter
Activation: "XX" = Become effective just after recorded into the controller
"X" = Become effective after restarting the controller
"-" = The parameter cannot be changed (fixed value)
Parameter name
Controller ID
IO pattern
ACC/ DEC pattern
S-motion rate
Stroke (+)
Stroke (-)
Max speed
Max ACC/DEC
Def In position
Range
Identification number (axis) parameters of serial
1 to 32
communications are set.
This is the fixed value for this controller (It should not be
Fixed
changed).
value
The value for this should be 64(Standard).
This is the fixed value for this controller (It should not be
Fixed changed).
value This defines the trapezoid acceleration/ deceleration
parameter.
Fixed This is the fixed value for this controller (It should not be
value changed).
This defines the positive (+) side limit of the position.
(Unit: mm)
*1)
Any value greater than the [stroke (+)] value cannot be
entered in the "Position" field data of step parameter
setup.
This defines the negative (-) side limit of the position.
(Unit: mm)
*1) Any value less than the [stroke (-)] value cannot be
entered in the "Position" field data of step parameter
setup.
This defines the maximum limit of the speed (Unit: mm/s).
Any value greater than the [Max speed] value cannot be
*1)
entered in the "Speed" field data of step parameter setup.
*2)
This defines the maximum limit of the ACC/ DEC (Unit:
2
mm/s ).
*1)
Any value greater than the [Max ACC/ DEC] value cannot
be entered in the "Accel" field data of step parameter
setup.
This defines the range to activate the INP output when the
*1)
electric actuator is within it after the return to origin
operation. (Unit: mm)
Caution
Description
- 40 –
Activation
X
-
-
-
XX
XX
XX
XX
XX
