3.2 Parts description

The detailed descriptions of each part are as follows:
⑨
No. Label
① PWR Power LED (green)
②
ALM Power LED (red)
③ -
Connector (26 pins)
④ SI
Connector (8 pins)
Encoder connector
⑤ ENC
Motor power
⑥ MOT
connector (6 pins)
Power connector
⑦ PWR
Applicable electric
⑧ - actuator model
number label
⑨ - Controller label
⑩ -
③
④
⑤
⑥
⑦
Name
Power ON/No alarm: Green light
Data (step data, parameter) writing /green light flashing
Do not turn off the input power supply for the controller while the
data is being written (power supply LED (green) flashes).
Data (step data, parameter) may not be written correctly.
Power ON/Alarm: Red light
Parallel I/O Used to connect PLC, etc. with the I/O cable.
(11 inputs and COM, 13 outputs and COM)
Serial I/O
Used to connect the teaching box, PC, etc.
(16 pins)
Used to connect the actuator cable.
Used to connect the controller power supply (24 VDC) with the
power supply plug.
(6 pins) Common power (-) ,Motor power (+) ,Control power (+) ,Stop signal
(+) ,Lock release (+)
The label indicating the applicable electric actuator model.
It also indicates the type of the parallel I/O (PNP/NPN).
The label indicating the part number of the controller.
Functional ground
FG (When the controller is mounted, tighten screws and connect the
grounding cable)
①
②
⑧
Label of controller version
⑩
A side
Description
Caution
- 17 –
A side view
(controller version)
yV S１.０ N
N
S1120010001
