Teaching Box - SMC Networks JXC5H Operation Manual

（8） Teaching box
外形寸法図
(1)
(4)
(5)
(6)
(7)
ＬＥＣ－Ｔ１－３□Ｇ□

Teaching box

Cable length
U
3 3ｍ
Original language
J Japanese
E
English
Conversion cable for connecting the teaching box
P5062-5 (Cable length: 0.3 m)
* Required for connecting the teaching box and JXC controller
(2)
No
(1)
(2)
(3)
(4) Stop guard
(3)
(5)
(6)
(7)
(8)
(8)
- 13 –
Enable switch
Nil
S
Stop switch
G
Indication
LCD Liquid crystal display (with backlight)
Ring The ring to hang the teaching box.
When the switch is pressed, the switch
Stop switch locks and it stops.
Turn clockwise to release the lock.
Protector for the stop switch
Switch to prevent unintentional operation
Enable
of Jog test function.
switch
* Does not apply to other functions e.g.
(Option)
data change
Key switch Entry switches
Cable 3m length
The connector to be connected to the CN4
Connector
of the controller
No enable switch
Equipped with enable
switch
With Stop switch
Function
No.JXC※-OMY0002
