7.11 Configuring Position and Time
100% (by Kp Scale Factor) the output will put out the additional pulses until the accumulated
overage is gone.
7.10.5 Configuring Relays for Trigger Mode
In the Configure Relay Parameters window, select "Triggers" to link one of the four relays to a
specific trigger. Thereafter, when the specified event occurs, it will actuate that relay. Figure 7.20
illustrates "Triggers" selected for Relay 4, with User Trigger 1 as the triggering mechanism. Triggers
may be User (DSP), Power Quality or System Triggers.
7.10.6 Configuring and Using Communication Mode
1. Select a relay and select Communications Mode button on the right panel.
2. When ready to manually switch the relay, select Manual Override Relay at the bottom of the
left panel. Click either Open or Close to switch the relay as shown in Figure 7.21.
Figure 7.21: Configure Relays for Manual Override Mode
7.11 Configuring Position and Time
Use the Position and Time window to set up Time Preferences, and to assist the GNSS receiver
during initial start up. See Figure 7.22. Time preferences are for the 1133A front panel display
Figure 7.20: Configure Relays for Trigger Mode
67
