13.6 Harmonic and Harmonic Summary Data Structure

13.6 Harmonic and Harmonic Summary Data Structure
DNP Modbus
Type:Index Input Reg.
AI:96 30097
AI:97 30098
AI:98 30099
AI:99 30100
AI:100 30101
AI:101 30102
AI:102 30103
AI:103 30104
AI:104 30105
AI:105 30106
AI:106 30107
AI:107 30108
AI:108 30109
AI:109 30110
AI:110 30111
AI:111 30112
AI:112 30113
AI:113 30114
AI:114 30115
AI:115 30116
AI:116 30117
AI:117 30118
AI:118 30119
AI:119 30120
AI:120 30121
AI:121 30122
AI:122 30123
AI:123 30124
AI:124 30125
AI:125 30126
AI:126 30127
AI:127 30128
Table 13.4: Harmonic and Harmonic Summary Register Values
For technical details on how the Model 1133A measures harmonics and calculates harmonic
summary data, see Section 11.14, in the Functional Description. DNP users should be able to
download any of the Quantities listed in Table 13.4 by using the Index value associated with it.
For example, call C-phase, RMS Harmonic Current with index number 111. The measurement
resolution is determined by the maximum current divided by 32767.
Quantity
A RMS Harmonic Voltage
A RMS Harmonic Voltage, K-Factor Adjusted
A Voltage RMS THD, Fundamental Reference
A Voltage RMS THD, Total Signal Reference
A Voltage K-Factor
A RMS Harmonic Current
A RMS Harmonic Current, K-Factor Adjusted
A Current RMS THD, Fundamental Reference
A Current RMS THD, Total Signal Reference
A Current K-Factor
C RMS Harmonic Voltage
C RMS Harmonic Voltage, K-Factor Adjusted
C Voltage RMS THD, Fundamental Reference
C Voltage RMS THD, Total Signal Reference
C Voltage K-Factor
C RMS Harmonic Current
C RMS Harmonic Current, K-Factor Adjusted
C Current RMS THD, Fundamental Reference
C Current RMS THD, Total Signal Reference
C Current K-Factor
B RMS Harmonic Voltage
B RMS Harmonic Voltage, K-Factor Adjusted
B Voltage RMS THD, Fundamental Reference
B Voltage RMS THD, Total Signal Reference
B Voltage K-Factor
B RMS Harmonic Current
B RMS Harmonic Current, K-Factor Adjusted
B Current RMS THD, Fundamental Reference
B Current RMS THD, Total Signal Reference
B Current K-Factor
Reserved
Reserved
141
Full Scale
Vmax = 32767
Vmax = 32767
100% = 32767
100% = 32767
32.767 = 32767
Imax = 32767
Imax = 32767
100% = 32767
100% = 32767
32.767 = 32767
Vmax = 32767
Vmax = 32767
100% = 32767
100% = 32767
32.767 = 32767
Imax = 32767
Imax = 32767
100% = 32767
100% = 32767
32.767 = 32767
Vmax = 32767
Vmax = 32767
100% = 32767
100% = 32767
32.767 = 32767
Imax = 32767
Imax = 32767
100% = 32767
100% = 32767
32.767 = 32767
0
0
