13.8 Energy Register Values

13.8 Energy Register Values
DNP Modbus
Type:Index Input Reg.
PIc:0 30729–30730
PIc:1 30731–30732
PIc:2 30733–30734
PIc:3 30735–30736
PIc:4 30737–30738
PIc:5 30739–30740
PIc:6 30741–30742
PIc:7 30743–30744
PIc:8 30745–30746
PIc:9 30747–30748
PIc:10 30749–30750
PIc:11 30751–30752
PIc:12 30753–30754
PIc:13 30755–30756
PIc:14 30757–30758
PIc:15 30759–30760
PIc:16 30761–30762
PIc:17 30763–30764
PIc:18 30765–30766
PIc:19 30767–30768
PIc:20 30769–30770
PIc:21 30771–30772
PIc:22 30773–30774
PIc:23 30775–30776
PIc:24 30777–30778
PIc:25 30779–30780
PIc:26 30781–30782
PIc:27 30783–30784
PIc:28 30785–30786
PIc:29 30787–30788
PIc:30 30789–30790
PIc:31 30791–30792
PIc:32 30793–30794
PIc:33 30795–30796
PIc:34 30797–30798
PIc:35 30799–30800
Quantity
A Active Energy Delivered Register (Wh)
C Active Energy Delivered Register (Wh)
B Active Energy Delivered Register (Wh)
Total Active Energy Delivered Register (Wh)
A Active Energy Received Register (Wh)
C Active Energy Received Register (Wh)
B Active Energy Received Register (Wh)
Total Active Energy Received Register (Wh)
A Apparent Energy Delivered Register (VAh)
C Apparent Energy Delivered Register (VAh)
B Apparent Energy Delivered Register (VAh)
Total Apparent Energy Delivered Register (VAh)
A Apparent Energy Received Register (VAh)
C Apparent Energy Received Register (VAh)
B Apparent Energy Received Register (VAh)
Total Apparent Energy Received Register (VAh)
A Reactive Energy Register, Quadrant 1 (VARh)
C Reactive Energy Register Quadrant 1 (VARh)
B Reactive Energy Register Quadrant 1 (VARh)
Total Reactive Energy Register Quadrant 1 (VARh)
A Reactive Energy Register Quadrant 2 (VARh)
C Reactive Energy Register Quadrant 2 (VARh)
B Reactive Energy Register Quadrant 2 (VARh)
Total Reactive Energy Register Quadrant 2 (VARh)
A Reactive Energy Register, Quadrant 3 (VARh)
C Reactive Energy Register Quadrant 3 (VARh)
B Reactive Energy Register Quadrant 3 (VARh)
Total Reactive Energy Register Quadrant 3 (VARh)
A Reactive Energy Register Quadrant 4 (VARh)
C Reactive Energy Register Quadrant 4 (VARh)
B Reactive Energy Register Quadrant 4 (VARh)
Total Reactive Energy Register Quadrant 4 (VARh)
A Qh Delivered Register
C Qh Delivered Register
B Qh Delivered Register
Total Qh Delivered Register
Table 13.6: Energy Values
143
Full Scale
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
32-bit integer
