6.4 Connecting with the 1133A
6. IEEE 802.3I: Connect the Ethernet cable from a hub into the RJ-45 connector (IEEE 802.3I
port) at the rear of the 1133A. If you encounter problems see Appendix A, "Working with
Ethernet Connections," on page 151.
Serial Connection Summary
Connector
SERIAL-1
SERIAL-2
IEEE 802.3I
IEEE 802.3I
IRIG-B
Contact Outputs
6.4.3

Starting PSCSV

1. Verify that PSCSV is installed on the computer. If necessary download from
www.arbiter.com/.
2. Start PSCSV. Select the shortcut on the desktop, or use the Windows desktop Start menu.
3. Check the buttons on the Main and the Connection Toolbars. Several of the buttons should
be active, including the Folder, Question Mark and Open Connection.
6.4.4

Checking Communication Parameters on the 1133A

1. Press and hold the STATUS/TIME button on the 1133A for about three seconds and release
when you see the display change to another set of menus.
2. Keep pressing the STATUS/TIME button until you view the desired communications port
menu. To see a list of the various menus on the 1133A, see "Status/Time Button Secondary
Functions" in Section 5.2.5.
6.4.5

Opening a Connection

To configure the 1133A and access any stored data on it, you must open a connection between
your pc and the Model 1133A. The connection type can be RS-232, RS-485, internal modem and
Ethernet. An open connection is signified by a connection name appearing in the Connection
Window, and some new active icons.
Before attempting to make the software connection, make sure to connect a cable between the
your pc and the 1133A. For RS-232, RS-485 and modem, the connector is RJ-11 using a common
phone cord. For Ethernet, the connector is RJ-45 and using a CAT-5 cable.
Communication Standard
RS-232, RS-485, Modem, DNP 3.0, Modbus
RS-232, RS-485, Modem, DNP 3.0, Modbus
TCP/IP, DNP 3.0, Modbus
UDP Broadcast
IRIG-B000, Unmodulated
KYZ (SPDT, Form A/ Form B solid-state contact)
Table 6.1: Types and Uses of 1133A Serial Connections
43
Direction
Trans/Rec
Trans/Rec
Trans/Rec
Trans
Trans
Trans
