Arbiter Systems Power Sentinel 1133A Operation Manual page 160

140
Frequency, Flicker and Relative Phase Register Values, continued.
DNP Modbus
Type:Index Input Reg.
AI:76 30077
AI:77 30078
AI:78 30079
AI:79 30080
AI:80 30081
AI:81 30082
AI:82 30083
AI:83 30084
AI:84 30085
AI:85 30086
AI:86 30087
AI:87 30088
AI:88-95 30089-96
Quantity
A Voltage Relative Phase (to A Current)
A Current Relative Phase
C Voltage Relative Phase
C Current Relative Phase
B Voltage Relative Phase
B Current Relative Phase
Zero Sequence Voltage Relative Phase
Zero Sequence Current Relative Phase
Positive Sequence Voltage Rel. Phase
Positive Sequence Current Rel. Phase
Negative Sequence Voltage Rel. Phase
Negative Sequence Current Rel. Phase
Reserved (8 Values)
DNP 3.0 and MODBUS Data Structures
Full Scale
180deg =
Ref. = 0
180deg =
180deg =
180deg =
180deg =
180deg =
180deg =
180deg =
180deg =
180deg =
180deg =
0
32767
32767
32767
32767
32767
32767
32767
32767
32767
32767
32767
