13.5 Frequency, Flicker and Relative Phase Data Structure

13.5 Frequency, Flicker and Relative Phase Data Structure
DNP Modbus
Type:Index Input Reg.
AI:48 30049
AI:49 30050
AI:50 30051
AI:51 30052
AI:52 30053
AI:53 30054
AI:54 30055
AI:55 30056
AI:56 30057
AI:57 30058
AI:58 30059
AI:59 30060
AI:60 30061
AI:61 30062
AI:62 30063
AI:63 30064
AI:64 30065
AI:65 30066
AI:66 30067
AI:67 30068
AI:68 30069
AI:69 30070
AI:70 30071
AI:71 30072
AI:72 30073
AI:73 30074
AI:74 30075
AI:75 30076
Table 13.3: Frequency, Flicker and Relative Phase Register Values
Quantity
Frequency
Frequency Error
Frequency Rate of Change
Reserved
System Time Deviation (seconds)
System Time Deviation (cycles)
Instantaneous Flicker, A Voltage
Instantaneous Flicker, A Current
Instantaneous Flicker, C Voltage
Instantaneous Flicker, C Current
Instantaneous Flicker, B Voltage
Instantaneous Flicker, B Current
Reserved
Reserved
Reserved
Reserved
A Voltage Relative Phase
A Current Relative Phase
C Voltage Relative Phase
C Current Relative Phase
B Voltage Relative Phase
B Current Relative Phase
Zero Sequence Voltage Rel. Phase
Zero Sequence Current Rel. Phase
Positive Sequence Voltage Rel. Phase
Positive Sequence Current Rel. Phase
Negative Sequence Voltage Rel. Phase
Negative Sequence Current Rel. Phase
Full Scale
327.67 Hz = 32767
32.767 Hz = 32767
327.67 Hz/s = 32767
0
327.67 sec = 32767
3276.7 cycles = 32767
3276.7 Flicker = 32767
3276.7 Flicker = 32767
3276.7 Flicker = 32767
3276.7 Flicker = 32767
3276.7 Flicker = 32767
3276.7 Flicker = 32767
0
0
0
0
Ref. = 0
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
180deg = 32767
139
