Chapter 7
Configuring the Model 1133A
7.1

Introduction

This section covers configuring the 1133A and all of its functions. It is not possible to configure the
1133A from the front panel keypad. Configure the 1133A with PSCSV software. After configuring
the 1133A, data may be retrieved using PSCSV or any other software tool that works with C37.118,
DNP 3.0 or Modbus protocols.
7.1.1 1133A Configuration Options by Section
Communication Port Settings
C37.118 Synchrophasors
Measurement Parameters
1133A Security
Kp Register Scale Factors
UDP Broadcasting
7.1.2 Basic Configuration Requirements
1. Open a connection with the 1133A using PSCSV software. If necessary, see Section 6.4 for
basic information on connecting.
2. Log in to the 1133A with permission to configure. See Section 6.4.12
Any time you wish to configure the 1133A, make sure to meet these two requirements.
For information on opening a connection with the 1133A, see Chapter 6. If you do not have
permission to configure, you will need to review 1133A Security in Section 7.14, or see your system
administrator to set up permission.
7.2 Configuring an 1133A Communication Port
Use PSCSV to configure a port on the 1133A. "Configuring a Port" means setting up the specific
communication parameters of a given communication port in the Model 1133A.
WARNING: Do not change the communication port parameters of the same port being used
to communicate with the 1133A; an Invalid Data window will appear, and communications will be
terminated.
Position and Time
DNP 3.0 and Modbus
Scheduled Data Storage
Set Time Deviation
Relays or Contact Outputs
Flash Memory Management
